Stage ESC 214_214z_216_216z

สแตกเกอร์ไฟฟ้าแบบนั่งขับ 1.4 - 1.6 ตัน

ทุกรุ่น
เลือกรุ่น
  • ทุกรุ่น
  • ESC 214
  • ESC 216
  • ESC 214z
  • ESC 216z
  • ESC 316
  • ESC 316z
  • 2800 - 6200 mm
  • 1400 - 1600 kg
  • Display featuring steering position indicator and travel program selection.
  • Maximum speed and acceleration.
  • Ergonomic seating position for perfect all-round visibility.
  • multiPILOT for comfortable operation.
  • Initial lift available for uneven ground.

ESC 214-316 / 214z-316z

Series 2 and 3 of our ergonomic and robust ESC transverse-seated stackers are ideal for intensive applications at great heights and for transport over longer distances. Thanks to their compact design and stable frame, they are perfect for demanding applications in block warehouses or confined warehouse environments. Equipped with a powerful drive and lift motor, the ESC easily reaches high speeds and impresses with rapid acceleration when safely and efficiently transporting goods. The transverse seating position allows the operator to maintain all-round visibility at all times, while the multiPILOT enables easy changes of direction with minor steering movements. With the Series 2, you can manoeuvre easily within narrow aisle widths, while the Series 3 enables you to enjoy the best ride comfort thanks to increased legroom.

ลิเธียมไอออน

กล่องเทเลเมติกส์ในแพคเกจเริ่มต้น (ที่ติดตั้งไปกับตัวรถยกจากโรงงาน) ช่วยให้คุณสามารถบริหารจัดการฟลีทรถยกได้อย่างมีประสิทธิภาพ ทั้งช่วยให้คุณประหยัดเวลา พลังงาน และค่าใช้จ่าย กล่องเทเลเมติกส์สามารถดึงข้อมูลประวัติการใช้งานรถยกย้อนหลังและทำงานร่วมกับฮาร์ดแวร์และซอฟต์แวร์อื่นๆเพิ่มเติมได้.

คุณสมบัติพิเศษ

ภาพรวมรายละเอียดรุ่น

Model กำลังโหลด ยกสูง ความเร็วในการเดินทาง ความยาวโดยรวม แรงดันแบตเตอรี่
ESC 214 1,400 kg 5,350 mm 9.1 km/h 2,125 mm 24 V
ESC 216 1,600 kg 6,200 mm 9.1 km/h 2,125 mm 24 V
ESC 214z 1,400 kg 5,350 mm 9.1 km/h 2,140 mm 24 V
ESC 216z 1,600 kg 6,200 mm 9.1 km/h 2,140 mm 24 V
ESC 316 1,600 kg 6,200 mm 9.1 km/h 2,125 mm 24 V
ESC 316z 1,600 kg 6,200 mm 9.1 km/h 2,155 mm 24 V
